主要指标
9 kHz 至 4.5/6.5/8.5/14/20 GHz
2 或 4 端口，50 Ω，S 参数测试仪
提供 130 dB 宽广的动态范围、8 ms 快速测量速度和 0.005 dB/℃ 温度稳定度，可改善测量精度、提高产品良率并增加设计裕量
增强时域分析选件可对高速串行互连进行全面表征，增强您对设计的信心
所有选件均可升级，保护您的投资
描述
E5071C-TDR 是一款针对 ENA 网络分析仪的嵌入式应用软件，可提供适用于高速串行互连分析的综合解决方案。它针对信号完整性设计和验证提供了三大突破特性：简单、直观的操作、快速、准确的测量以及可靠的 ESD。
E5071C-TDR
Enhanced Time Domain Analysis
E5071C-008
Frequency offset mode
E5071C-010
Time domain analysis
E5071C-017 Removable Data Storage
E5071C-019 Standard Data Storage
E5071C-1A7 Calibration + Uncertainties + Guardbanding (Not Accredited)
E5071C-1CM Rack mount kit
E5071C-1CN Front handle kit
E5071C-1CP Rack mount and front handle kit
E5071C-1E5 High stability time
E5071C-240 2-port Test Set, 9 kHz to 4.5 GHz without Bias Tees
E5071C-245 2-port Test Set, 100 kHz to 4.5 GHz with Bias Tees
E5071C-260 2-port Test Set, 9 kHz to 6.5 GHz without Bias Tees
E5071C-265 2-port Test Set, 100 kHz to 6.5 GHz with Bias Tees
E5071C-280 2-port Test Set, 9 kHz to 8.5 GHz without Bias Tees
E5071C-285 2-port Test Set, 100 kHz to 8.5 GHz with Bias Tees
E5071C-2D5 2-port Test Set, 300 kHz to 14 GHz with Bias Tees
E5071C-2K5 2-port Test Set, 300 kHz to 20 GHz with Bias Tees
E5071C-440 4-port Test Set, 9 kHz to 4.5 GHz without Bias Tees
E5071C-445 4-port Test Set, 100 kHz to 4.5 GHz with Bias Tees
E5071C-460 4-port Test Set, 9 kHz to 6.5 GHz without Bias Tees
E5071C-465 4-port Test Set, 100 kHz to 6.5 GHz with Bias Tees
E5071C-480 4-port Test Set, 9 kHz to 8.5 GHz without Bias Tees
E5071C-485 4-port Test Set, 100 kHz to 8.5 GHz with Bias Tees
E5071C-4D5 4-port Test Set, 300 kHz to 14 GHz with Bias Tees
E5071C-4K5 4-port Test Set, 300 kHz to 20 GHz with Bias Tees
E5071C-790 Measurement wizard assistant software
E5071C-810 Add keyboard
E5071C-820 Add mouse
E5071C-A6J ANSI Z540-1-1994 Calibration
E5071C-UNQ Standard stability time
