介绍日本SMC氟素树脂管IL100-03
系列 适合管子外径 颜色
公制尺寸 英制尺寸
TL/TIL φ4,φ6,φ8,φ10,
φ12,φ19 φ1/8",φ3/16",φ1/4"
φ3/8",φ1/2",φ3/4",φ1" 半透明
特长 高使用压力1.0MPa以下 (20℃时)
高使用温度：260℃ (条件不同有所差别)
gradually close the
other side and
measure 2R at the
point where the
tubing folds or
flattens, etc
(Max. operating pressure) = 1/4 x (burst pressure drop coefficient) x (burst pressure at 20°C)
• When using a fluid in liquid form, the surge pressure must be no more than the maximum operating pressure.
A surge pressure higher than the maximum operating pressure can cause breakage of the fitting or bursting of the tubing.
Note 2) The minimum bending radius is measured using the method shown in the figure at the right.
Furthermore, an abnormal temperature increase due to adiabatic compression can cause tubing to burst.
To operate at a temperature other than 20°C, the operating pressure must be no more than the value calculated using the
equation below: When the value (calculated using the formula below) exceeds 1 MPa, the Max. operating pressure is 1 MPa.
At a temperature of
20°C bend the tubing
into a U shape. Then
with one side fixed,
