PHOENIX电源模块中文资料,QUINT-PS/1AC/24DC/40
电源 - QUINT-PS/1AC/24DC/40 - 2866789
用于DIN导轨安装的QUINT POWER电源，初级开关模式，采用SFB技术（选择性熔断技术），输入：1相，输出：24 V DC/40 A
保护等级 IP20
环境温度（运行） -25 °C ... 70 °C (> 60 °C Derating: 2.5 %/K)
环境温度（调试类型测试） -40 °C
环境温度（存放/运输） -40 °C ... 85 °C
允许的大相对湿度（操作） ≤ 95 % (25°C时，无冷凝)
安装高度 4000 m
QUINT-PS/12DC/12DC/8 2905007
QUINT-PS/12DC/24DC/ 5 2320131
QUINT-PS/12DC/24DC/ 5/RS 2910304
QUINT-PS/1AC/12DC/15 2866718
QUINT-PS/1AC/12DC/20 2866721
QUINT-PS/1AC/15DC/CS
QUINT-PS/1AC/24DC/ 3.5 2866747
QUINT-PS/1AC/24DC/ 5 2866750
QUINT-PS/1AC/24DC/ 5/CO 2320908
QUINT-PS/1AC/24DC/10 2866763
额定输出电压 24 V DC ±1 %
输出电压（USet）的设置范围 18 V DC ... 29.5 V DC (> 24 V DC，稳定容量限制)
额定输出电流（IN） 40 A (-25 °C ... 60 °C, UOUT = 24 V DC)
POWER BOOST (IBoost) 45 A (-25°C ... 40°C恒定，UOUT = 24 V DC )
选择性熔断 (ISFB) 215 A (12毫秒)
衰减 60 °C ... 70 °C (2.5%/K)
并连 是，用于冗余和增加容量
串连 是
残波 < 30 mVSS (额定值)
输出功率 960 W
典型响应时间 < 0.7 s
大空转功耗 14 W
大额定负载功率损耗 80 W
