RTD-806
高精度RTD探头，实验室应用
RTD-800 Series
高精度RTD探头，实验室应用
RTD-800 Series:高精度RTD探头，实验室应用
100 Ohm, Alpha=.00385 Pt RTD Sensor
Contains a "Class- A", PT100 Platinum RTD Sensing Element With a Resistance Vs. Temperature Curve Conforming to IEC60751 (Temperature Coefficient (Alpha) = .00385 ohm/ohm/°C)
Sensor Supplied with 3 feet of PFA-Insulated and Jacketed Cable
Subminiature MTP Series Connector Standard (Other Connectors Available)
Mating Connectors Included (Black Leads on Center and Wide Prong, Red on Other)
Precision RTD probes specialized for laboratory applications are available in 6 unique configurations to suite a variety of application needs. All units contain a 100 Ohm, Class A Platinum RTD Sensor and are supplied with an "MTP" style, 3-Pin Connector.
产品型号/产品描述
RTD-805 RTD element mounted in open-end stainless steel housing with PFA-insulated leads. Designed for air temperature measurement and monitoring of gas streams. 3' lead wire. Temp range: -50 to 230°C (-60 to 445°F)
RTD-806 RTD-806 features economical plastic housing. Temp Range: -50 to 230°C (-60 to 445°F)
RTD-809 Encapsulated sensor in stainless steel housing with PFA-insulated leads. Surface temperature measurement design, ideal for heat loss or compressor efficiency measurement. 3' lead wires. Temp Range: -50 to 230°C (-60 to 445°F)
RTD-810 Closed-end stainless steel tube with PFA-insulated leads. Rugged design is ideally suited for fluid measurements. Also for use in a wide variety of pressurized systems applications. 3' lead wires. Temp Range: -200 to 750°C (-328 to 1380°F)
RTD-830 Encapsulated sensor in screw-mounted aluminum housing with PFA-insulated leads. Sensor design provides low cost fast response, and is designed for easy mounting on flat surfaces. 3' lead wires. Temp Range: -50 to 230°C (-60 to 445°F)
RTD-850 Stainless steel housing with 1 /4 " hex head and #8-32 NC-2A threaded body. RTD sensor encapsulated in housing with PFA-insulated leads. Designed for applications requiring vibration and shock resistance. 3' lead wires. Temp Range: -50 to 230°C (-60 to 445°F)
RTD-860 Closed-end stainless steel tube with sensor mounted in tip. Stainless steel mounting plate with two (2) mounting holes welded to tube. PFA-insulated 3' lead wires. Temp Range: -200 to 230°C (-330 to 445°F)
Also Available:
RTD-880-100 OHMS Special high temperature, closed ended, 6 inch (150 mm) long stainless steel sheath with sensor in tip.
Containes a mounting bracket with two mounting holes affixed to the sheath, two 6" long 24 gage stripped leads with fiberglass insulation and a 100 ohm Platinum RTD with a temperature coefficient (alpha) of .00385
RTD-806
RTD-806
