ABB双电源转换开关 DPT63-CB010 C16 4P产品介绍：
ABB双电源转换开关 DPT63-CB010 C16 4P 【双电源转换开关（PC 级）产品概述】：
A.OT_C 双电源手动转换开关
B.具有隔离功能
C.开关断口可见，开关状态一目了然
D.可短时承受过载及短路电流
E.可带负载切换
F.可靠的机械联锁和挂锁功能
G.开关具有 3 个的位置：I-O-II
H.操作手柄可直接安装在开关上或柜门上
I.16-125 A 的开关可卡装在 DIN 导轨上
| 型号 | 额定工作电流 | 物料号 |
| AC-21...22A (A) | ||
| OT16F3C | ||
| T25F3C | 25 | 10092085 |
| OT40F3C | 40 | 10092086 |
| OT63F3C | 63 | 10092087 |
| OT80F3C | 80 | 10092088 |
| OT100F3C | 100 | 10092089 |
| OT125F3C | 125 |
10092090 |
| 四极 | ||
| 型号 | 额定工作电流 | 物料号 |
| AC-21...22A (A) | ||
| OT16F4C | ||
| T25F4C | 25 | 10092092 |
| OT40F4C | 40 | 10092093 |
| OT63F4C | 63 | 10092094 |
| OT80F4C | 80 | 10092095 |
| OT100F4C | 100 | 10092096 |
| OT125F4C | 125 | 10092097 |
ABB双电源转换开关 DPT63-CB010 C16 4P OTM_C 双电源电动转换开关
A-额定电流可高达 2500A
B-具有隔离功能
C-开关断口可见，开关状态一目了然
D-可短时承受过载及短路电流
E-可带负载切换
F-可靠的机械及电气联锁，确保用电
G-可手动、电动操作
H-设计的内置离合器，使手动操作更
I-开关具有 3 个的位置：I-O-II
| 三极 | ||
| 型号 | 额定工作电流 | 物料号 |
| AC-21...22A (A) | ||
| OT160E03CP-104 | ||
| OT200E03CP-104 | 200 | 10065353 |
| OT250E03CP-104 | 250 | 10065354 |
| OT315E03CP-104 | 3 | |
| T400E03CP-104 | 400 | 10065356 |
| OT630E03CP-104 | 630 |
10065362 |
| OT800E03CP-104 | 800 |
10065363 |
ABB双电源转换开关 DPT63-CB010 C16 4P
OTM_C_D 双电源自动转换开关
一.额定电流可高达 2500A
二.配备 10D、11D、3D 或 8D 控制器
三.具有隔离功能
四.开关断口可见，开关状态一目了然
五.可短时承受过载及短路电流
六.可带负载切换
七.可靠的机械及电气联锁，确保用电
八.可手动、电动及自动操作
九.设计的内置离合器，使手动操作更
十.开关具有 3 个的位置：I-O-II
十一.单相检测
十二.10D / 11D 控制有 N 线接错及保护功能
十三.3D / 8D 控制器设有检测功能
十四.8D 控制器设有通讯及故障记忆功能
| 型号 | 极数 | 额定电流 | 配合的 | 物料号 |
| In | 控制器 | |||
| (A) | ||||
| OTM32E4C3D220C | 4 | 32 | 3D | 10100622 |
| OTM40E4C3D220C | 4 | 40 | 3D | 10100623 |
| OTM50E4C3D220C | 4 | 50 | 3D | 10100624 |
| OTM63E4C3D220C | 4 | 63 | 3D | 10100625 |
| OTM80E4C3D220C | 4 | 80 | 3D | 10100626 |
| OTM100E4C3D220C | 4 | 100 | 3D | 10100627 |
| OTM125E4C3D220C | 4 | 125 | 3D | 10100636 |
| OTM160E4C3D220C | 4 | 160 | 3D | 10100637 |
| OTM200E4C3D220C | 4 | 200 | 3D | 10100638 |
| OTM250E4C3D220C | 4 | 250 | 3D | 10100639 |
| OTM315E4C3D220C | 4 | 315 | 3D | 10100640 |
| OTM400E4C3D220C | 4 | 400 | 3D | 10100641 |
| OTM630E4C3D220C | 4 | 630 | 3D | 10100642 |
| OTM800E4C3D220C | 4 | 800 | 3D | 10100643 |
| 型号 | 极数 | 额定电流 | 配合的 | 物料号 |
| In | 控制器 | |||
| (A) | ||||
| OTM32E3C8D220C | 3 | 32 | 8D | 10102070 |
| OTM40E3C8D220C | 3 | 40 | 8D | 10102071 |
| OTM50E3C8D220C | 3 | 50 | 8D | 10102072 |
| OTM63E3C8D220C | 3 | 63 | 8D | 10102073 |
| OTM80E3C8D220C | 3 | 80 | 8D | 10102074 |
| OTM100E3C8D220C | 3 | 100 | 8D | 10102075 |
| OTM125E3C8D220C | 3 | 125 | 8D | 10102082 |
| OTM160E3C8D220C | 3 | 160 | 8D | 10102083 |
| OTM200E3C8D220C | 3 | 200 | 8D | 10102084 |
| OTM250E3C8D220C | 3 | 250 | 8D | 10102085 |
| OTM315E3C8D220C | 3 | 315 | 8D | 10102086 |
| OTM400E3C8D220C | 3 | 400 | 8D | 10102087 |
| OTM630E3C8D220C | 3 | 630 | 8D | 10102094 |
| OTM800E3C8D220C | 3 | 800 | 8D | 10102095 |
| OTM32E4C8D220C | 4 | 32 | 8D | 10102076 |
| OTM40E4C8D220C | 4 | 40 | 8D | 10102077 |
| OTM50E4C8D220C | 4 | 50 | 8D | 10102078 |
| OTM63E4C8D220C | 4 | 63 | 8D | 10102079 |
| OTM80E4C8D220C | 4 | 80 | 8D | 10102080 |
| OTM100E4C8D220C | 4 | 100 | 8D | 10102081 |
| OTM125E4C8D220C | 4 | 125 | 8D | 10102088 |
| OTM160E4C8D220C | 4 | 160 | 8D | 10102089 |
| OTM200E4C8D220C | 4 | 200 | 8D | 10102090 |
| OTM250E4C8D220C | 4 | 250 | 8D | 10102091 |
| OTM315E4C8D220C | 4 | 315 | 8D | 10102092 |
| OTM400E4C8D220C | 4 | 400 | 8D | 10102093 |
| OTM630E4C8D220C | 4 | 630 | 8D | 10102096 |
| OTM800E4C8D220C | 4 | 800 | 8D | 10102097 |
| 型号 | 极数 | 额定电流 | 配合的 | 物料号 |
| In | 控制器 | |||
| (A) | ||||
| OTM32F3C10D380C | 3 | 32 | 10D | 10112493 |
| OTM40F3C10D380C | 3 | 40 | 10D | 10112494 |
| OTM50F3C10D380C | 3 | 50 | 10D | 10112495 |
| OTM63F3C10D380C | 3 | 63 | 10D | 10112496 |
| OTM80F3C10D380C | 3 | 80 | 10D | 10112497 |
| OTM100F3C10D380C | 3 | 100 | 10D | 10112498 |
| OTM125F3C10D380C | 3 | 125 | 10D | 10112499 |
| OTM160E3C10D380C | 3 | 160 | 10D | 10100573 |
| OTM200E3C10D380C | 3 | 200 | 10D | 10100574 |
| OTM250E3C10D380C | 3 | 250 | 10D | 10100575 |
| OTM315E3C10D380C | 3 | 315 | 10D | 10100576 |
| OTM400E3C10D380C | 3 | 400 | 10D | 10100577 |
| OTM630E3C10D380C | 3 | 630 | 10D | 10100578 |
| OTM800E3C10D380C | 3 | 800 | 10D | 10100579 |
| OTM32F4C10D380C | 4 | 32 | 10D | 10112500 |
| OTM40F4C10D380C | 4 | 40 | 10D | 10112501 |
| OTM50F4C10D380C | 4 | 50 | 10D | 10112502 |
| OTM63F4C10D380C | 4 | 63 | 10D | 10112503 |
| OTM80F4C10D380C | 4 | 80 | 10D | 10112504 |
| OTM100F4C10D380C | 4 | 100 | 10D | 10112505 |
| OTM125F4C10D380C | 4 | 125 | 10D | 10112506 |
| OTM160E4C10D380C | 4 | 160 | 10D | 10100581 |
| OTM200E4C10D380C | 4 | 200 | 10D | 10100582 |
| OTM250E4C10D380C | 4 | 250 | 10D | 10100583 |
| OTM315E4C10D380C | 4 | 315 | 10D | 10100584 |
| OTM400E4C10D380C | 4 | 400 | 10D | 10100585 |
| OTM630E4C10D380C | 4 | 630 | 10D | 10100586 |
| OTM800E4C10D380C | 4 | 800 | 10D | 10100587 |
| 型号 | 极数 | 额定电流 | 配合的 | 物料号 |
| In | 控制器 | |||
| (A) | ||||
| OTM32F3C11D380C | 3 | 32 | 11D | 10112507 |
| OTM40F3C11D380C | 3 | 40 | 11D | 10112508 |
| OTM50F3C11D380C | 3 | 50 | 11D | 10112509 |
| OTM63F3C11D380C | 3 | 63 | 11D | 10112510 |
| OTM80F3C11D380C | 3 | 80 | 11D | 10112511 |
| OTM100F3C11D380C | 3 | 100 | 11D | 10112512 |
| OTM125F3C11D380C | 3 | 125 | 11D | 10112513 |
| OTM160E3C11D380C | 3 | 160 | 11D | 10100601 |
| OTM200E3C11D380C | 3 | 200 | 11D | 10100602 |
| OTM250E3C11D380C | 3 | 250 | 11D | 10100603 |
| OTM315E3C11D380C | 3 | 315 | 11D | 10100604 |
| OTM400E3C11D380C | 3 | 400 | 11D | 10100605 |
| OTM630E3C11D380C | 3 | 630 | 11D | 10100606 |
| OTM800E3C11D380C | 3 | 800 | 11D | 10100607 |
| OTM32F4C11D380C | 4 | 32 | 11D | 10112514 |
| OTM40F4C11D380C | 4 | 40 | 11D | 10112515 |
| OTM50F4C11D380C | 4 | 50 | 11D | 10112516 |
| OTM63F4C11D380C | 4 | 63 | 11D | 10112517 |
| OTM80F4C11D380C | 4 | 80 | 11D | 10112518 |
| OTM100F4C11D380C | 4 | 100 | 11D | 10112519 |
| OTM125F4C11D380C | 4 | 125 | 11D | 10112520 |
| OTM160E4C11D380C | 4 | 160 | 11D | 10100609 |
| OTM200E4C11D380C | 4 | 200 | 11D | 10100610 |
| OTM250E4C11D380C | 4 | 250 | 11D | 10100611 |
| OTM315E4C11D380C | 4 | 315 | 11D | 10100612 |
| OTM400E4C11D380C | 4 | 400 | 11D | 10100613 |
| OTM630E4C11D380C | 4 | 630 | 11D | 10100614 |
| OTM800E4C11D380C | 4 | 800 | 11D | 10100615 |
ABB双电源转换开关 DPT63-CB010 C16 4P
东莞市恒轩机电有限公司销售ABB，三菱，富士，施耐德低压电气产品，需要了解更多型号，请我们哦！
