包装秤传感器FSSB-C4/200kg 单点式高精度传感器

FSSB-C4 单点式传感器

单点式；不锈钢材质；高精度；高稳定性；安装简便、快速；适用于包装秤和配料系统等；





产品特点和优势



Features主要特点
  Single point load cell
  Senior stainless steel
  High accuracy
  High stability
  Easy to install
  Suitable for package systems and batching systems, etc.
  单点式
  不锈钢材质
  高精度
  高稳定性
  安装简便、快速
  适用于包装秤和配料系统等
Capacities量程
? 30kg,50kg,60kg, 100kg, 150kg, 200kg, 250kg, 300kg, 350kg
Specification 技术参数
Rated Output 额定输出 2.0mV/V ±0.1%
Zero Balance 零点平衡 ±3 of rated output
Creep after 30 minutes 蠕变 ±0.03% of rated output
Nonlinearity 非线性 ±0.03% of rated output
Hysteresis 滞后 ±0.03% of rated output
Repeatability 重复性 ±0.03% of rated output
Temp. effect on output 灵敏度温漂 ≤0.002% of applied output/oC
Temp. effect on zero 零点温漂 ≤0.002% of rated output/oC
Safe Temp. Range 可用温度范围 -10oC to + 70oC
Temp. Compensated 温度补偿范围 -10oC to + 40oC
Safe Overload 安全载荷 150%
Input Impedance 输入阻抗 387 ohm ± 20 ohm
Output Impedance 输出阻抗 350 ohm ± 5 ohm
Insulation Resistance 绝缘阻抗 ≥5000 M ohm (50V DC)
Rated Excitation 激励电压 10V DC/AC
Maximum Excitation 大激励电压 15V DC/AC
Cable Length 导线长度 6m/10m
Cable Color Code 导线颜色 Red(+E) Black(-E) Green(+S) White(-S)
