吉时利/Keithley 2410数字源表
能够测量高达1100V的电压和1A的电流，输出功率20W功率
主要特点及优点:
设计用于高速直流参数测度
2400系列提供宽动态范围：10pA to 10A, 1μV to 1100V, 20W to 1000W
四象限工作
0.012%的度，51?2 的分辨率
可程控电流驱动和电压测量钳位的6位线电阻测量
在4 1/2 数位时通过GPIB达1700读数/秒
内置快速失败/通过测试比较器
可选式接触检查功能
数字I/O提供快速分选与机械手连
接GPIB, RS-232, 和触发式连接面板
TestPoint and LabVIEW驱动
吉时利SourceMeter?（数字源表）系列是专为那些要求紧密结合激励源和测量功能，要
求精密电压源并同时进行电流与电压测量的测试应用而设计的。所有源表均由一个精密的、
低噪声、高稳定的带回读功能的直流电源和一个低噪声、高重复性、高输入阻抗的5 1/2位
多功能表组成，形成了紧凑的单通道直流参数测试仪。其功能相当于电压源、电流源、电压
表、电流表和电阻表的综合体。通信、半导体、计算机、汽车与医疗行业的元件与模块制造
商都将发现，源表仪器对于各种特征分析与生产过程测试都极具实用价值。
2410型高压源功率为20W，能够提供和测量从±5μV（源）和±1μV（测量）到±1100V的电
压，以及从±10pA到±1A的电流。由于具有较高的电压源范围，2410非常适合于电阻和电压
系数测试、变阻器、高压二极管、开关、齐纳管、射频二极管和整流器的测试。2410在提供
1100V电压的同时能够测量20mA的电流，具有测试这些器件所需的特殊分辨率。
The Keithley SourceMeter? series is designed for applications that require tight coupling
of excitation sources and measurement functions.Precision voltage source and at the same
time for current and voltage measurement of the test application design. All source tables
are composed of a sophisticated,Low noise, high stability DC power supply with readback
function and a low noise, high repeatability, high input impedance of 5 1/2 bitMulti-function
table, forming a compact single-channel DC parameter tester. Its function is equivalent to the
voltage source, current source, voltageTable, ammeter and resistor table complex. Communi
cations, semiconductor, computer, automotive and medical industry components and module
manufacturingWill find that the source table instrument for a variety of features and production
process testing are highly practical value.
The Model 2410 high-voltage source is capable of supplying and measuring from ± 5μV (source)
and ± 1μV (measurement) to ± 1100V Voltage, and a current from ± 10pA to ± 1A. Due to the high
voltage source range, the 2410 is well suited for resistors and voltages Coefficient tests, rheostats,
high voltage diodes, switches, zener, RF diodes and rectifiers. 2410 On offer 1100V voltage can
measure the current of 20mA at the same time, have the special resolution required to test these
devices precisely.
