费斯托FESTO蓝色螺旋型塑料气管,PUN-10X1,5-S-2-BL
丰富的插入式接头品种以满足各种气动应用需求:
有1000多个款式供选择
温度高可达到 80癈
和温度相关的压力高可达到 14 bar.
采用了特殊的密封系统，因此泄漏值很低气管的插拔容易
适用的气管外径为 4, 6, 8, 10, 12 和16 mm
连接螺纹从 R1/8...R1/2 以及G1/8...G1/2.
气管:
多派生型: PUN
耐压型 (高 14 bar) PAN
耐水解: PUN-H
PUN-10X1,5-S-2-BL
PUN-6X1-BL
PUN-8X1,25-BL
PUN-8X1,25-SI
PUN-E-10x1,25-BL
PUN-E-12x1,6-BL
PUN-V0-8X1,25-BL
PUN-V0-6X1-BL
PUN-6X1-BL
PUN-8X1，25-BL
PUN-12X2-BL
PUN-6X1-SI
PUN-8X1,25-SI
PUN-12X2-BL
费斯托FESTO蓝色螺旋型塑料气管,PUN-10X1,5-S-2-BL
螺旋型塑料气管PUN-10X1,5-S-2-BL产品代号: 197597
高弹性, 具有很强的耐水解能力
工作长度 2 m
外径 10 mm
块长度 0.43 m
内径 7 mm
线圈直径 80 mm
绕线圈数 22
和温度相关的工作压力 -0.95 ... 10 bar
环境温度 -35 ... 60 °C
产品重量 250 g
颜色 蓝色
肖氏硬度 D 52 +/-3
材料备注 不含有黄铜和PTFE
气管的材料信息 TPE-U(PU)
