H100-15371 H100-15372 H100-15373 H100-15374 H100-15375 H100-15376
美国UE压力开关 回差可调压力控制器 死区可调的全新原装进口压力开关
H100系列特征
·一个SPDT输出
·耐用型压力、真空、压差和温度开关
·与介质相容的种类广泛的压力传感元件
·环氧树脂外壳,设计满足 NEMA 4 X/IP 65的要求
·热跟踪和低温保护温度模式
·有专为泵类设计的死区可调开关
Model A djustable Set Adjustable Deadband Over Range Proof
Point Range Pressure* Pressure**
Low End Mid Range High End
psi bar psi bar psi bar psi bar psi bar psi bar
Buna N diaphragm and O-Ring nickel-plated brass 1/4” NPT (female) pressure connection; includes adjustable deadband microswitch
15731 3 to 30 0,2 to 2,1 1.5 to 4 0,1 to 0,3 2 to 4.5 0,1 to 0,3 2.5 to 5 0,2 to 0,3 500 34,5 600 41,4
15732 5 to 100 0,3 to 6,9 3 to 6 0,2 to 0,4 4 to 7.5 0,3 to 0,5 5 to 9 0,3 to 0,6 500 34,5 600 41,4
15733 9 to 300 0,6 to 27,0 4 to 11 0,3 to 0,8 5 to 13 0,3 to 0,9 5 to 16 0,3 to 1,1 500 34,5 600 41,4
15734 15 to 500 1,0 to 34,5 8 to 25 0,6 to 1,7 9 to 28 0,6 to 1,9 10 to 31 0,7 to 2,1 1500 103,4 2500 172,4
15735 30 to 1000 2,1 to 68,9 9 to 30 0,6 to 2,1 10 to 35 0,7 to 2,4 30 to 90 2,1 to 6,2 1500 103,4 2500 172,4
15736 100 to 1700 6,9 to 117,2 25 to 60 1,7 to 4,1 40 to 80 2,8 to 5,5 50 to 100 3,4 to 6,9 2000 137,9 2500 172,4
UE压力开关常用型号
H100-520 H100-521 H100-522 H100-523 H100-524 H100-525 H100-530 H100-531 H100-532 H100-533 H100-534 H100-535 H100-15737 H100-171 H100-172 H100-173 H100-174 H100-560 H100-561 H100-562 H100-563 H100-564H100-565 H100-566 H100-567 H100-701 H100-702 H100-703 H100-704 H100-705 H100-706 H100-190 H100-191 H100-192 H100-193 H100-194 H100-188 H100-189 H100-218 H100-610 H100-612 H100-490 H100-491 H100-492 H100-493
H100-15623 H100-15731 H100-15732 H100-15733 H100-15734 H100-15735 H100-15736
H100-494 H100-183 H100-184 H100-185 H100-186 H100-483 H100-484 H100-485 H100-486 H100-487 H100-488 H100-489 H100-218 H100-270 H100-274 H100-358 H100-376 H100610 H100-10614 H100-616 H100-15884 H100-680
