0811405063力士乐模拟电路比例放大板
特点:
-适用于控制4WRA类型,公称规格尺寸6和10的2X系列和WRZ 7X系列比例阀
-装配在欧洲格式100*160mm结构形式的印制板中,适合安装在机架中。
-控制值输入:
差动输入±10V
四个控制值输入,启动电压为±10V
电流输入4至20mA
-通过24V输入或跳线改变内部控制值信号极性
-通过相位识别(24V输入)或斜坡时间启动(24V输入)选择斜坡时间
配套的板卡机架:
-19英寸机架类型VT19101,VT19102,VT19103和VT19110
-VT12302类型全封闭式板卡机架仅供在控制柜中安装
-配套的供电单元:
-VT-NE30-2X类型,紧凑型电源115/230VAC→24VDC,108VA
0811405063力士乐模拟电路比例放大板
订货代码:
"VT-VRRA1-527-2X/V0/*"
"VT-V"--比例阀放大器
"R"--用于具有电气反馈的阀的液压组件
"R"--阀类型:方向控制阀
"A"--控制:模拟
"527"--以下型号的序列号:先导控制阀,规格 6
"2X"--组件系列 20 到 29(20 到 29:技术数据和插脚分配不变)
"V0"--标准样本型号
"*"--选件:
2STV = 适用于带良好线性特性区间的非线性阀芯的先导式方向阀
PO-IS = 油路块安装插装阀控制 A → X
放大器为标准导轨安装式，用于驱动单个电磁铁比例阀。放大器对电磁比例阀提供所需电流以校准阀的调整量，使之与输入信号相对应。放大器用于开环控制系统。放大器通过对电磁铁提供一切换电流，使阀的调整与输入信号（电压或电流）成比例。为保证阀的调整精度，可用放大器上的电位器调整增益和偏流。供给放大器的输入信号通常是由外界电位器或PLC控制单元提供。放大器由斜坡发生器、偏流调整、增益调整、PWM调制、使能控制以及保护电路组成，电流调节范围0-3安，负载阻抗2-45Ω。
用途：该比例放大器用于驱动比例压力阀、比例流量阀、比例变量泵等单比例阀；或驱动单比例泵；比例线圈电阻3-50Ω。
特点及优点：PWM调制；电流负反馈恒流控制；斜坡时间（上升和下降时间）独立可调；参考电源输出；带振颤信号；高精度，小型，环保型；使用寿命长、发热小、功耗低、适应性强。
