压力开关J400-358-M201 河北UE开关代理 不锈钢压力开关0-13.8bar
美国UE开关授权代理 ＆ 授权证书
西安奥信 王工⑱⑨/⑥⑥⑨④/②⑤⑨④
Q10919/23827 www.xaaxyb.com 技术咨询请点击：王晓
400系列压力开关、差压开关、温度开关
J402-523 J402-525 J402-530 J402-531 J402-533 J402-535 J400-570 J400-571
J400-572 J400-S126B J400-S134B J400-S137B J400-S144B J400-S146B J400-358
J400-S156B J400-S164B J400-361 J400-376 J400-610 J400-16014 J402-S146B
J400-614 J400-126 J400-134 J400-137 J400-144 J400-146 J400-156 J400-164
J400-270 J400-274 J400-442 J400-443 J400-448 J400-450 J400-451 J400-452
J400-453 J400-454 J400-440 J400-441 J400-449 J402-441 J402-449 J402-570
J402-571 J402-572 J402-S126B J402-S134B J402-S137B J402-S144B J402-S156B
J402-358 J402-361 J402-376 J402-610 J402-614 J402-126 J402-134 J402-137
J402-144 J402-146 J402-156 J402-164 J402-270 J402-274 J402-442 J402-443
J402-448 J402-450 J402-451 J402-452 J402-453 J402-454 J403-570 J403-571
J403-572 J403-S126B J402-16014 J402-S164B J403-S134B J403-S137B J403-358
J403-S144B J403-S146B J403-S156B J403-S164B J403-16014 J403-361 J403-376
J403-610 J403-614 J403-126 J403-134 J403-137 J403-144 J403-146 J403-156
J403-164 J403-270 J403-274 J403-442 J403-443 J403-448 J403-450 J403-451
型号及参数
型号 可调整设定范围 死区 zd压力 耐压**
Model Adjustable Set Point Range Deadband Over Range Proof
J400-270 0 to 13.8 bar 0.1 to 0.6 bar 13.8 bar 17.2 bar 1/4" NPTF Ni Plated Brass-Ph Bronze
J400-358 0 to 13.8 bar 0.1 to 0.6 bar 13.8 bar 17.2 bar 1/4" NPTF 316L st/st
J400-S164B 0 to 13.8 bar 20.7 mbar to 0.1 bar 13.8 bar 13.8 bar 1/2" NPTF 316L st/st
J400-274 0 to 20.7 bar 0.1 to 0.7 bar 20.7 bar 24.1 bar 1/4" NPTF Ni Plated Brass-Ph Bronze
J400-361 0 to 20.7 bar 0.1 to 0.6 bar 20.7 bar 24.1 bar 1/4" NPTF 316L st/st
J400-376 0 to 34.5 bar 0.2 to 0.8 bar 34.5 bar 39.6 bar 1/4" NPTF 316L st/st
美国UE山西代理J400-358参数及尺寸
压力开关J400-358-M201 河北UE开关代理 不锈钢压力开关0-13.8bar
