S-20 ; 0...4 MPa gauge; 4...20 mA, 2-wire威卡变送器
德国威卡WIKA授权代理 ＆ 授权证书
西安奥信 王工⑱⑨/⑥⑥⑨④/②⑤⑨④
Q10919/23827 www.xaaxyb.com 技术咨询请点击：王晓
常用型号
S-20 ; 0...1 MPa gauge; 4...20 mA, 2-wire
S-20 ; 0...1.6 MPa gauge; 4...20 mA, 2-wire
S-20 ; 0...10 bar gauge; 0 ... 10 V, 3-wire
S-20 ; 0...10 MPa gauge; 4...20 mA, 2-wire
S-20 ; 0...13 MPa; 4...20 mA, 2-wire
S-20 ; 0...15000 psig; 4...20 mA, 2-wire
S-20 ; 0...16 bar gauge; 4...20 mA, 2-wire
S-20 ; 0...1600 bar; 4...20 mA, 2-wire
S-20 ; 0...2.5 bar gauge; 0 ... 10 V, 3-wire
S-20 ; 0...2.5 MPa gauge; 4...20 mA, 2-wire
S-20 ;0...25 MPa gauge; 4...20 mA, 2-wire
S-20 ; 0...3MPa; 0 ... 10 V, 3-wire
S-20 ; 0...3MPa; 4...20 mA, 2-wire
S-20 ; 0...4 MPa gauge; 0...5 V,3-Wire
S-20 ; 0...4 MPa gauge; 4...20 mA, 2-wire
技术参数
S-20；0…4兆帕表压；4…20毫安，2线
@直流8…35V非线性：0.5%BFSL
G 1/4 B EN 837标准
密封：铜
角型连接器，包括DIN175301-803 A配套连接器
；U+=1，U-=2
允许介质温度：-30…+100°C
压安全：2次
抗冲击和振动：100g冲击，20g振动
校准温度：15。。。25摄氏度
S-20 ; 0...4 MPa gauge; 4...20 mA, 2-wire
@ DC 8...35 V Non-linearity: 0.5% BFSL
G 1/4 B EN 837
Sealing: copper
angular connector DIN 175301-803 A mating connector included
; U+=1, U-=2
Permissible medium temperature: -30...+100°C
Overpressure safety: 2 times
shock and vibration resistance: 100 g shock, 20 g vibration
Calibration Temperature: 15 ... 25 °C
Approvals: cULus
Performance Level: without
with test protocol
Specifications: according to WIKA data sheet PE 81.61
Certificates: without
