ECPE84-2
ECPE84-2 The 1394-SJT22-A module is a GMC Turbo system module from Allen-Bradley/Rockwell Automation. The module features a 32-bit central processing unit. Also, it features a +/-10 Volts DC analog input. The module is powered by an AC power supply with a voltage rating of between 380 Volts AC and 460 Volts AC at a frequency of 50 to 60 Hertz. The nominal power output of 17 to 22
kilowatts while its bus voltage is rated at 530 Volts DC to 680 Volts DC. When the 1394-SJT22-A system module is being interfaced with an external axis drive, the 1394-DIM drive interface module is recommended. The drive interface module acts as an interface between the 1394-SJT22-A module and the external axis drive. The Allen-Bradley 1394-SJT22-A module belongs to the Allen-Bradley 1394 modular multi-axis motion control and drive system family. The module, like others in this family, provides a direct connection line for 3-phase input power, efficient IGBT power conversion, and a slide-and-lock module-to-module connection system. Depending on the system module that is used, the maximum of axis that can be supported is 4 axis. where axis can be interfaced to a motor. The Allen-Bradley 1394-SJT22-A module is completely programmable and supports configuration with the graphical motion control language (GML). Additionally, the module supports standard communication options such as the RS-232, RS-422, and DH-485 options. By having a turbo option, the 1394-SJT22-A module executes programs much faster compared to standard modules in the same family.
IS200STCIH2A标准
IS200STCIH2A是Mark VIE端子板。该板用外部I/O端接。这主要用于GE Speedtronic Mark VIE系列。此外，Mark VIE是一个灵活的多应用平台。它还为单工、双冗余和三冗余系统提供高速网络I/O。
IS200STCIH2A是一种填充有SMD组件和连接器的多层PCB。接线板的一部分是可拆卸连接器。STCI端子板也有不同版本。
可靠性
IS200STCIH2A板非常可靠，因此不易损坏。但操作不当和存储不良会影响卡的功能。因此，我们建议在建议的条件下将卡存放在静电敏感存储箱中IS200STCIH2A是GE根据Mark VI系列开发的单触点输入端子板。Simplex Contact Input端子板是一种小触点输入端子板，设计用于DIN导轨或平面安装。该板接受来自外部电源的24触点输入，标称24、48和125 V dc励磁。触点输入具有噪声抑制功能，以防止浪涌和高频噪声。PAIC I/O块与模块兼容。I/O块插入D型连接器，并通过以太网与控制器通信。仅支持单工系统。
IS200STCIH2A安装
STCI与塑料绝缘体一起安装在钣金托架上，然后将其安装在DIN导轨上。
STCI加绝缘体可以安装在金属板组件上，然后用螺栓固定在机柜中。触点输入通常使用#18 AWG电线直接连接至接线板。
护罩应端接在单独的支架上。STCIH2有一个直角集管，可接受各种商用可插拔接线端子，共52个端子。
活动
功能和车载信号调节与TBCI上的相同，但它们适用于24、48和125 V dc励磁。输入励磁范围分别为16至32 V dc、32至64 V dc和100至145 V dc。阈值电压为励磁电压的50%。图中显示了触点感应电路。在前21个电路上，触点输入电流限制为2.5 mA，在电路22至24上限制为10 mA。
通过重置聚合物正温度系数保险丝，24 V直流电源的电流限制为0.5 A。滤波器可降低高频噪声，并抑制信号输入点附近每个输入端的浪涌。离散输入电压信号被路由到I/O处理器，后者将其转换为数字信号并发送给控制器。
IS200STCIH2A特性
E1和E2是端子板两侧端子环上的标签。
一个37针（内螺纹）D型连接器和一个三位内螺纹插头与电路板上的端子排相对。
在木板的短边上，在木板上切下两个圆孔，一个相对另一个。板上还有80多个电阻器、电容器、二极管和单个集成电路。
产品属性
可用通道数-24个干接触电压输入通道。
标称励磁电压为24 V dc，浮动，范围为18.5至32 V dc（可插拔TB）
电流输入-对于需要24 V dc的应用：前21个电路消耗2.5 mA，而*三个消耗10 mA。
输入硬件滤波器，4 ms
I/O板故障检测-触点输入处的励磁电压损失，在测试模式下不响应的触点输入
GE Speedtronic Mark VIe控制器更换部件的*广泛分类可在控制世界找到。我们的*可以随时帮助您满足Mark VIe要求。369-HI-0-M-0-0-E is a motor management relay that is manufactured by GE Multilin. The control power is 50-300 VDC / 40-265 VAC. There are no optional RTD inputs on this relay. This unit includes an optional metering package. There is no optional fiber optic port. This relay provides protection and monitoring for 3-phase motors and their associated systems. The 369 can ‘learn’ individual motor parameters and adapt itself to individual applications. In order to improve the protective capabilities of the relay, the user may adjust the motor inrush current, the cooling rates, and/or the acceleration time. If you have any questions about this motor management relay or the associated series or manufacturer, please contact AX Control.
