PR6423/002-041要选择位置，请考虑其他驱动器和设备距离足够远，不会导致温度过高。驱动器还必须通风良好，
在某些情况下需要风扇来冷却现场。如果使用风扇，请确保风扇处于良好状态，并适合空间大小。冷空气通过驱动器底部的通风口进入驱动器。空气通过驱动装置，从部件中带走热量。在驱动器顶部，热空气离开驱动器。
当您计划安装时，请注意空间周围的墙壁是否很热。相邻房间的驱动器和其他设备可能会加热墙壁。您可以考虑选择其他空间来安装驱动器或在其他设备未使用时使用驱动器。这样，墙壁会更凉爽，不会产生过多的热量。
Product De
ion
The GE DC Power Connect Board DS200PCCAG10ACB serves as an interface between the drive and the SCR power bridge. Once you install the replacement DS200PCCAG10ACB board you might have reason to download the configuration file of the drive to a laptop for review. You can edit the configuration file and change parameters to update the operation of the drive with the replacement board installed.
To download the parameters file, first make sure you have a serial cable that has the matching ports you need to connect the drive to the laptop. Also, make sure the serial port on the laptop is configured properly to communicate with the drive. Use the commands on the control panel to initiate the download and when complete a message displays on the display panel that the download is complete.
You can use the laptop to check the operation of the replacement board by viewing the diagnostic file. You can also access the editing software on the laptop to alter the board's parameters. When you have completed the updates, upload the file back to the drive. Use the control panel to start the download procedure and when the operation is complete, a will be message displayed.
To replace the DS200PCCAG10ACB board, you must disconnect all power to the drive. To do that, access the 3-phase power supplies that provide current to the drive. Then, remove the fuses from the power supplies. Next, you can open the bay that contains the boards and remove the wires and connectors.
Frequently Asked Questions about DS200PCCAG10ACB
What does DS200PCCAG10ACB do for lower horsepower controllers?
For low-to-medium horsepower controllers, DS200PCCAG10ACB includes snubber circuits to control spikes across the AC lines, DC bus, and gate drivesr. For higher horsepower controllers, some or all of the snubber circuits are omitted from the DS200PCCAG10ACB board.
How many jumpers does DS200PCCAG10ACB have?
DS200PCCAG10ACB has four wire jumpers. DS200PCCAG10ACB's jumpers are JP1, JP2, WP3, and WP4. The jumpers on DS200PCCAG10ACB select system voltage and determine snubber capacitor connectors.
What type of snubbers does DS200PCCAG10ACB connect to?
Because DS200PCCAG10ACB is a G10 board group PCCA, DS200PCCAG10ACB only connects to DC snubbers.
Where can I find the manual for DS200PCCAG10ACB?
We can send you the manual for DS200PCCAG10ACB. We have the manual to DS200PCCAG10ACB on file and will send the manual upon request. The manual for DS200PCCAG10ACB is Manual GEI-100161 - The GE Industrial Control Systems PCCA Power Connect Card Manual.产品描述
