库号：D51637
脉冲控制仪SBFEC-DMK-5CS
循环间隔调节范围
1~99分钟Minute
Adjustable Range of Cycle
Interval
控制输入信号
开关触点
Control Input Si gnal
Switc h Contact
使用环境
-25"C~ +55"C
Use Envi ronment
相对湿度不过85%
无严重的腐蚀气体和导电尘埃
无激烈震动或冲击
Relative humidity of air does not exceed 85%
No serious corrosion gas and conducting dust
No acute vibration or shock
输入电压/输出电压列表Table for Input Voltage / Output Vol tage
RC
输入电压Input Vol tage
输出电压Output Voltage
空白Blank
220VAC
24VDC
| HH
220VAC
220VAC
| MM
110VAC .
110VAC
|ML
110VAC
24VDC
LL
24VDC
24VDC
指标Technical Index
额定输入电压
220VAC(1土10%) 50-60HZ, (或其他规格)
Rated Input Vol tage .
(or other speci fications)
额定输出电压
24VDC ( 或其他规格)
Rated 0utput Voltage
(or other speci ficat ions )
额定输出电流
1A
Rated Output Current
功耗
≤8W
Power Consumption
输出脉冲宽度调节范围
10 ~990毫秒Millisecond
Adjustable Range of Output Pulse
Width
输出脉冲间隔调节范围
1~99秒Second
Adjustable Range of Output Pulse
激活
Interval
转到”设
