耐震压力表213.53.063压力指示器-1-0bar威卡真空表

上海WIKA压力表 耐震213.53.063  压力指示器 威卡真空表

西安奥信  Q：10919/23827   王工 18966942594

213.53.063 0.6 bar G1/4B back mount

213.53.063 0.6 MPa 2nd scale bar G1/4B back mount

213.53.063 0.6 MPa 2nd scale psi G1/4B lower mount

213.53.063 0.6 MPa 2nd scale psi M14*1.5 lower mount

213.53.063 -1 bar 1/4 NPT lower mount

213.53.063 1 barg 1/4 NPT lower mount

213.53.063 1 MPa M12 x 1.5 lower mount

213.53.063 1 MPa R 1/4-ISO7 (DIN2999) lower mount

213.53.063 1.6 MPa M14*1.5 back mount

213.53.063 -1/+1.5 bar 2nd scale MPa M12 x 1.5 lower moun

213.53.063 -1/+1.5 bar G1/4B lower mount

213.53.063 -1/+15 bar G1/4B back mount

213.53.063 -1/+25 bar /deg.C(R22)

213.53.063 -1/+3 bar G1/4B lower mount

213.53.063 -1/+5 bar 1/4 NPT back mount

213.53.063 -1/+5 bar 2nd scale MPa G1/4B lower mount

213.53.063 10 bar 1/4 NPT back mount

213.53.063 10 bar G1/4B back mount

213.53.063 10 bar M14x1.5 lower mount

213.53.063 10 MPa 1/4 NPT lower mount

213.53.063 10 MPa 2nd scale psi G1/4B lower mount

213.53.063 100 bar 2nd scale MPa 1/4 NPT back mount

213.53.063 100 bar M14*1.5 lower mount

213.53.063 100 MPa 2nd scale bar G1/4B lower mount

213.53.063 100 psi 1/4 NPT lower mount

213.53.063 100 psi 2nd scale bar 1/4 NPT back mount

213.53.063 100 psi 2nd scale bar M14*1.5 back mount

213.53.063 100 psi 2nd scale MPa 1/4 NPT lower mount

213.53.063 100 psi M14*1.5 lower mount

2 kPa 2nd scale bar G1/4B lower mount

20 psi 2nd scale MPa 1/4 NPT lower mount

基本参数：

外壳材质：不锈钢

接口材质：铜合金

表盘直径：63毫米

安装方式：径向、轴向

充液状况：212.53.063不充液；213.53.063充液耐震

213.53.050耐震压力表

213.53.063耐震压力表

213.53.100耐震压力表

描述

213.53型充液波登管压力外壳采用不锈钢制成，接液部分由铜合金制成。

213.53充液压力表符合国际行业标准EN 837-1对波登管压力表的要求。

由于表内有液体填充，压力元件和运动被有效地缓冲。因此，这些仪表特别适用于高动态负载点的测量，如频繁的压力波动或振动。

213.53充液压力表表壳标准尺寸有50、63和100毫米，并符合IP65防护等级。该压力表的准确度可达到1.0级，可广泛应用于工业中。

安装在控制面板时，轴向安装连接的压力表可以配备一个安装边或三角凸边及安装支架。
