Erler Zimmer 7200天然骨骼全身模体
来源：深圳为尔康科技有限公司
发布时间：2018-06-27 14:34:41
德国Erler Zimmer 7200天然骨骼全身模体，EZ 7200全身模体包含一个真实的人体骨骼，可以像患者一样拍摄真正的X射线图像。使用真实的骨架可以提供小的导向结构，这对于塑料骨架来说是不可能的。
在组装这个模体时，我们特别注意关节空间的正确尺寸。所有关节都可移动地安装，允许定位在所有正常的X射线位置。手臂可以向上移动，这使得模体适合用于CT下的各种骨质检查。
每个德国Erler Zimmer 7200天然骨骼全身模体，EZ 7200全身模体都是手工制作的的; 它的尺寸和外观可能不同。根据不同的模体，它可能有一些病态，外形可能因骨架的大小而异。新版本与德国着名放射学家学校合作重新设计，适合放射学领域所有教育需求。
每个德国Erler Zimmer 7200天然骨骼全身模体，EZ 7200全身模体包含一个完整的人体骨骼，我们不会结合几个骨骼的骨骼。
骨头不会被切割或修改。
没有用于固定骨头的金属棒或其他金属部件。
关节由橡胶和纺织带固定。该模体是专为培训医疗X射线成像，并允许所有的定位，由于生活般的关节。
这个模体只出售与医疗使用证明。生活规模。
This model is unique in the world and provides excellent training opportunities for positioning and alignment techniques in projection radiography. It should be part of the basic equipment of any radiographic school.
The phantom contains a real human skeleton, which allows taking real X-ray images like in a patient. Using a real skeleton provides even smallest guiding structures which is impossible with a plastic skeleton.
During assembly of this phantom we pay special attention to the correct size of joint spaces. All joints are moveably mounted allow positioning in all normal x-ray positions. The arms can be moved upwards which makes the phantom suitable for use in all kinds of osseous examinations under CT.
Each phantom is hand-made one of a kind; it may differ in size and appearance. Depending on the individual phantom it may have some pathologies, outer shape may differ depending on size of the skeleton. The new version was re-designed in co-operation with a well-known German school for radiographers and fits all needs for education in radiography.
- Each phantom contains a complete human skeleton, we do not combine bones from several skeletons.
- The bones are not cut or modified.
-
There are no
l rods or other l parts used to fix the bones. - The joints are secured by rubber and textile straps. The phantom is designed for training of medical x-ray imaging and allows all positioning due to the life-like articulations.
This phantom is only sold against proof of medical use. Life size.
