3500/15127610-01自动化备件卡件BENTLY
来源：厦门雄霸电子商务有限公司
发布时间：2022-10-21 17:19:31
轴振：每个滑动支持轴承上配置一对X/Y方向（互为垂直安装）的轴振测点，采用本特利3300XL系列电涡流传感器进行测量。
轴位移：压缩机组的每个推力轴承处配置双冗余的轴向位移测点；采用本特利3300XL系列电涡流传感器进行测量。
瓦振：每个滚动支持轴承上配置两个瓦振测点（水平和垂直方向安装），采用本特利330500系列Velomitor压电式振动速度传感器进行测量。
轴承温度（如适用）：每个滑动支持轴承及推力轴承均配置轴瓦温度测点；推力轴承的工作面和非工作面应同时配置温度测点。
齿轮箱壳振（如适用）：每个齿轮箱的输入和输出轴的支持轴承处各配置一对X/Y方向壳振测点；采用本特利330400系列压电式振动加速度传感器进行测量。
2.3500配置要求
Servo parameters:
If the servo gain is set too large, it is recommended to manually or actively adjust the servo parameters from the beginning; Acknowledge the setting of the time constant of the speed response filter. The initial value is 0, and you can test to increase the setting value; The electronic gear ratio is set too large, so it is recommended to restore to the factory setting; Resonance of servo system and mechanical system, test and adjust the frequency and amplitude of notch filter.
Mechanical system:
The coupling connecting the motor shaft and the equipment system deviates, and the mounting screws are not tightened; Poor engagement of pulleys or gears will also cause load torque changes. Test no-load operation. If it is normal during no-load operation, check whether the combination part of the mechanical system is abnormal; Recognize whether the load inertia, torque and speed are too large, and test the no-load operation. If the no-load operation is normal, reduce the load or replace the driver and motor with larger capacity. Application of Bently 3500 in steel, electric power, chemical and petrochemical industry and measuring points for vibration monitoring
